53mm Heavy Duty Drawer Slides
53mm Non-Locking Heavy-Duty Drawer Slides - 90 kg/pair
Versatile non-locking 53mm slides for industrial drawers and storage systems. Q235 cold-rolled steel, 250-1500 mm lengths, side or flat mounting, and a rated load capacity of 90 kg per pair.
A versatile telescopic slide for industrial drawers, storage trays and equipment access where free movement is preferred. Multiple thickness options support different project requirements.
Technical Data
Width: 53 mm
Material: Q235 cold-rolled steel
Available lengths: 250-1500 mm
Rated load capacity: 90 kg per pair
Mounting options: Side mount or flat mount
Finish options: Blue zinc plating or color zinc plating
Material thickness options: 1.8 x 1.8 x 1.8 mm; 2.0 x 1.8 x 1.8 mm; 2.0 x 1.8 x 2.0 mm
Typical Applications
Industrial drawers, vehicle storage, tool cabinets, cargo systems, vending machines and equipment enclosures.
Selection Notes
Choose the slide length according to the available installation depth and required extension. Calculate the moving load as a complete system, including the drawer or tray, stored equipment, brackets and accessories. Load performance can vary with slide length, mounting method, fasteners, load distribution and operating conditions.
Contact RUNMAO Technology Limited with your required length, load, mounting orientation, application and quantity so we can help confirm a suitable specification.
